The Ashcroft® 1000 pressure gauge offers reliability and performance for general industrial applications.
Easily customizable, this model is an ideal solution for pressure measurement.
Ashcroft 1000 Pressure Gauge

Specs

Accuracy
± 3-2-3% span (ASME B40.100, Grade B)
Pressure Ranges
Vacuum to 6,000 psi
Dial Size
4 1/2" steel case
Socket
Bronze Bourdon tube / brass socket
Connection
1/4" NPT lower connection only
Options
Optional black rubber boot

Features

  • PowerFlex™ movement provides superior resistance to shock, vibration and pulsation; extends product life and reduces maintenance costs
  • True Zero™ reduces reading errors by using a "zero zone" instead of conventional dial pins (posts); this ensures product safety, integrity and system control
  • FlutterGuard™ (option) reduces movement wear and eliminates pointer flutter; extends product life and allows easy gauge readability
